Venture offers Latest state of the art model of fiber laser marker design to ensure stable and constant light path, excellent for marking. Economic , cost-effective marking machine. Reliable product quality and overall cutting ability (Multi-Functional, Applicable for marking Materials like Iron, Steel, Brass, Silver, Gold, Aluminium, PVC, Acrylic, Double Color Board, Leather, Shell, Coconut Shell, Ox Horn, Resin Animal Grease, ABS Board, Lamp Shade, etc). To mark all kinds of materials with less investment.. Advanced features ensure high productivity, ease of operations and high quality output.
Features:
- Low Noise, Low Vibration, Smooth Operation.
- More Reliable, Industrial Design for Better Precision.
- Advanced Micro Controller.
- Easy to Operate & Compact in Size.
- Available in Both Honey Comb & Knife Bed.
- Automatic loop option ensuring the best production range.
- Higher Acceleration Ability.
- With optional rotary attachment, it can achieve fine marking for various Metal & Non-metal cylindrical and tubular materials.
- Suitable for marking a variety of Metal & Non-metal materials.
- Less power consumption.
- Can acheive 24/7, 365 Days production.
Specifications:
Laser Source
Output Power
Scanner
Controller
Wavelength
Cooling Mode
Power Supply
Laser Lifespan
Focus Lens
Software
Origin
Marking Area
Working Speed
Power Consumption
Repeat Mode
Electrical Requirements
Operating Temperature
Machine Dimensions
Total Weight
Pulse Fiber Laser
20 w 30 w 50 w (0-100%)
JCZ Scan Head
JCZ Controller
1064 nm
Air Cooled
(AC 230 V + -10 % )
Approximate 1,00,000 Hours
F100/F163/F210/F254/F300
Ezcad
Make in India
100/200/300 sq.mm
0-7000 mm/sec
700 W
Foot Pedal Switch
Single Phase 230V AC Stabalizer & spike free
18 c to 45 c
700L x 600W x 1300H mm
100 Kgs (Approx)
